Air Operated Double Diaphragm Pumps

AODD - 150 (Sizr : ½” x ½”)
CAPACITY0-2 m³/hr
PRESSURE0-5 kg/cm²
AIR CONSUMPTION 2-6 SCFM
AIR PRESSURE 20-100 PSIG


AODD - 300 (Size : 1” x 1”)
CAPACITY0-6 m³/hr
PRESSURE0-7 kg/cm²
AIR CONSUMPTION 5-18 SCFM
AIR PRESSURE 20-150 PSIG


AODD - 400 (Size : 1 ½” x 1 ½”)
CAPACITY0-15 m³/hr
PRESSURE0-8 kg/cm²
AIR CONSUMPTION 10-35 SCFM
AIR PRESSURE 20-150 PSIG


AODD - 500 (Size : 2” x 2” & 2 ½” x 2 ½”)
CAPACITY0-28 m³/hr
PRESSURE0-7 kg/cm²
AIR CONSUMPTION 5-50 SCFM
AIR PRESSURE 20-150 PSIG


AODD-800 (Size : 3” x 3”)
CAPACITY0-50 m³/hr
PRESSURE0-7 kg/cm²
AIR CONSUMPTION 20-150 SCFM
AIR PRESSURE 20-150 PSIG
